Located in Litchfield County and run by a team of hard-working blue-collar Americans, we’re here to make sure you get the hydraulic hoses you need, whenever you need them.

Is your hydraulic system underperforming?

Hydraulic Hoses Near Me offers expert repair services to bring it back to peak efficiency. Our skilled and certified technicians offer 24-hour 7 days a week hose cylinder repair.

We can handle everything from cylinders and control valves to hydraulic pumps and beyond..

We carry 2 wire hoses, 4 wire hoses, and 6 wire hoses.

Along with all types of different types of fittings. Here is to name a few.

1. BSP (British Standard Pipe) Threads:

• BSPP (Parallel): Uses a straight thread, often with a flat face and O-ring for sealing.
• BSPT (Tapered): Uses a tapered thread, typically sealing with metal-to-metal contact, often with an O-ring or bonded washer.

2. JIC (Joint Industry Council) Fittings:

• 37° Flare: Uses a 37-degree flare seat for a metal-to-metal seal, with straight threads.
• SAE J514: JIC fittings are defined by the SAE J514 standard.

3. ORFS (O-Ring Face Seal) Fittings:

• Flat Face with O-ring: The male fitting has a straight thread and an O-ring, which seals against a flat face on the female fitting.
• SAE J1453: ORFS fittings are defined by the SAE J1453 standard.

4. O-Ring Boss Fittings:

• Chamfered Port: The female port has a chamfered edge where the O-ring seals.
• Straight Threads: Uses straight threads for a strong mechanical connection.

5. “Cat Flat” ( Flat Face Quick Connect):

• Flat Face: A flat face design for a quick and easy connection, often used in hydraulic systems.
• Hydraulic Systems: Commonly used for connecting hydraulic lines under pressure.

6. Light DIN (DIN 2353 Light Series) Fittings:

Compression Style: Features a 24° cone end for a metal-to-metal seal, with a compression ring and cutting ring for secure hose grip.

Light Duty: Designed for lower pressure applications, typically up to 500 bar, ideal for general industrial hydraulics.
DIN 2353: Defined by the DIN 2353 standard, ensuring compatibility across European systems.

7. Heavy DIN (DIN 2353 Heavy Series) Fittings:

High-Pressure Compression: Uses a 24° cone for sealing, with reinforced compression and cutting rings to handle extreme pressures.

Heavy Duty: Built for demanding environments, supporting pressures up to 800 bar or more, common in heavy machinery.

DIN 2353: Adheres to the DIN 2353 standard, providing robust performance in high-vibration settings.

We carry hydraulic hoses in sizes of -4 -6 -16 -20 in 2 wire and sizes -12 -16 -20 -24 in 4 wire. We are also carrying suction hoses for your machine as well as rebuilding hydraulic cylinders.

If you have a need for non-conductive hoses, give us a ring and let us know what you have.
